泊头市卓远机械设备制造有限公司

6000*8000米，大T型槽平板订做

大型T型槽平台 ，铸铁平板，装配平台订做咨询：

公司名称：泊头市卓远机械设备制造有限公司
注册地址：河北省泊头市交河开发区
传真号码：0317-8031093
联系方式：(河北)15369812793 褚连胜

T型槽平台的制造工艺

T型槽平台在浇注完成后开始用振动清沙和人工除沙并清理铸铁平台毛坯周围的废弃物，清沙完毕后铸件自然放凉并开始第一次回火（时效处理），铸件在回火窑升温至780°并在窑种和窑的温度同时降至50°方可出窑。铸铁平台的铸件在粗加工的时候使用的是济南产龙门刨床和断面铣床使铸铁平台四周及上下面成正方形或是长方形，如果需要开T型槽必须在刨完平面后放置一天后才能开T型槽或是U型槽、矩型槽等加工。如果客户需要的精度较高个光洁度较高，那经过粗加工后必须用我厂自有的昆明机床厂产的6000*3000的数控龙门铣床进行精加工，数控龙门铣床加工后的精度直线度和平面度每米误差0.008mm，光洁度可以控制在1.2以内经过人工抛光后光洁度最高可以达到0.8。如果在铸铁平台上进行钻孔或是绞螺纹孔也可以用数控龙门铣床进行一次性完成，精度高，光洁度高。

Manufacturing process of T-slot platform
After the pouring is completed, the T-slot platform starts to use sand for vibration and manual sand removal and cleans the waste around the blank of the cast iron platform. After the sand is finished, the castings naturally cool down and start the first tempering (aging treatment), and the castings are back. The kiln is heated to 780 ° and the kiln and kiln temperature are simultaneously reduced to 50 ° to exit the kiln. The cast iron platform castings are used in the roughing process. The gantry planer and section milling machine are used to make the cast iron platform square or rectangular around the top and bottom. If you need to open the T-slot, you must place it for one day after the plane is finished. Type groove or U-shaped groove, rectangular groove and other processing. If the customer needs higher precision and higher finish, after roughing, it must be finished with 6000*3000 CNC gantry milling machine produced by our own Kunming Machine Tool Factory. The precision straightness of CNC gantry milling machine after processing The flatness is 0.008mm per meter, and the finish can be controlled within 1.2. After manual polishing, the finish can reach 0.8. If drilling or twisting the threaded hole on the cast iron platform, it can also be completed in one time with a CNC gantry milling machine with high precision and high finish.
